Made With KiCad
These are some KiCad designed projects that have been made by users. If you want to be featured along the other showcases on this page please submit a merge request on GitLab if you meet the contributing guidelines for requirements on adding a project!
TFGPS01: Drone multi-constellation GNSS receiver
ThunderFly s.r.o.
TFGPS01 is a GNSS receiver designed for UAVs. The module has improved RF noise immunity and supports multiple navigation systems. Therefore the module is capable of receiving GPS, GLONASS, Galileo, and BeiDou navigation signals. It is designed primarily for use on small drones. The TFGPS can also function as a standalone UART GPS or as a USB GPS receiver.
The module has several features for UAVs. For example, it has a pass-through I2C port, payload interface, integrated beeper and safety LED or integrated connector for an external safety switch, and safety LED.
TFSLOT01A: Drone indicated airspeed sensor
ThunderFly s.r.o.
TFSLOT is Low speed airspeed sensor for UAVs. The device is equipped with electronics, which contains the required differential pressure sensor and an IMU unit. The sensor can be used as an external compass for the autopilot and it can improve the estimation of orientation in space. Accelerometer data, on the other hand, can be used to check vibrations. In contrast to classical Pitot tube, the TFSLOT design is perfect choice for low airspeed measurement.
Tiny Reflow Controller
Rocket Scream Electronics
An open source all-in-one Arduino compatible reflow controller powered by ATtiny1634R.
Tokay Lite: ESP32 Edge AI Camera
MAXLAB.IO
Tokay Lite is the ESP32 camera development board ideal for low-power image processing applications on the edge.
Tokay Lite can be used as standalone devkit to aid developers with a convinient tool or be embedded in the bigger system to augument it with the vision and image processing data.
ToucheLibre
Lilian Tribouilloy
ToucheLibre is an ergonomic wooden keyboard. Designed under openhardware philosophie and with ecological sensitivity.
Be the luthier of your writings.
This is a summary of our values: to make a beautifull artisanal objet; an useful object in according to your needs and your health; to give an artistic look to inspire your work; a handshaking between craftsman and customer.
Turmlabor nixie clock
Ludwig Tesar
Another nixie clock joining the internet of things. Using IN14 nixie tubes, an ESP12e or alternatively a DS3231 RTC.
Ubertooth One
Great Scott Gadgets
Ubertooth One is an open source 2.4 GHz wireless development platform suitable for Bluetooth experimentation.
UPSat
Libre Space Foundation
The first open source satellite
UPSat is a 2U Cubesat satellite constructed and delivered by Libre Space Foundation, started by University of Patras as part of the upsatQB50 mission with ID GR-02.
USB armory
Inverse Path / F-Secure
The USB armory from Inverse Path is an open source hardware design, implementing a flash drive sized computer.
The compact USB powered device provides a platform for developing and running a variety of applications.
