These are some KiCad designed projects that have been made by users. If you want to be featured along the other showcases on this page please submit a merge request on GitLab if you meet the contributing guidelines for requirements on adding a project!



A64-OLinuXino is a single-board computer running Linux & Android. The design based on a 64-bit ARM CPU and includes 1 or 2 GB DDR3 RAM, 4 GB flash memory, microSD card socket, WiFi & BLE4.0, Ethernet, HDMI & audio output.

View Project


Leon Anavi

ANAVI Flex is an open source Raspberry Pi HAT for IoT prototyping and home automation applications. It has infrared receiver and transmitter, relay, buzzer, button, RGB LED and UART pins for debugging. The board also supports 1602 LCD display module and up to 5 I2C sensors.

View Project

ANAVI Infrared pHAT

Leon Anavi

ANAVI Infrared pHAT is an add-on board that converts Raspberry Pi in a powerful remote control. It features two IR transmitters, IR receiver, three slots for I2C sensor modules, UART pins for debugging and EEPROM with board manufacturer information.

View Project

ANAVI Light Controller

Leon Anavi

ANAVI Light Controller is a certified open source hardware WiFi device for controlling a 12 V RGB LED strip. It also supports I2C sensor modules for light, temperature, humidity, and gesture recognition.

View Project


Leon Anavi

ANAVI Light pHAT is a Raspberry Pi add-on board for controlling 12V RGB LED strip. Furthermore, it has three slots for I2C sensor modules, slot for PIR motion sensor, UART pins for debugging and EEPROM with board manufacturer information.

View Project

ATMEGA328 Motor Board

Antonio Morales

A general purpose motor controller designed with kicad around the ATmega328 micro controller and L298P motor driver. It can drive four motors with various input options.

View Project

Axiom motor controller

EV Power Designs Inc.

Axiom is a high power, high performance 100kW+ motor controller based upon the VESC platform for compatibility with firmware and GUI. It is designed for driving 650V 600A IGBTs and comes with many safety features.

View Project

Blixten a 6LoWPAN Gateway

Jonas Persson

An open source "ethernet – to – 6lowpan" gateway intended for use for some LED lighting control. It is four layer single load board with DRAM running with a linux kernel.

View Project


Antonia Stevens (ant)

Boatcontrol is an open hardware design for a marine grade SMART/IoT electrical distribution panel and electronics platform (boat) controller.

It’s an I/O breakout board capable of switching 32 onboard latching relays and optionally 32 momentary/latching relays using addon boards switching up to 60A AC/DC 0-400V per circuit.

The "smart" part is provided by either a Raspberry Pi HAT or a Nvidia Jetson (Nano/Xavier NX) either of which can be mounted on the board.

View Project


The CIAA Project

The CIAA Project is an open hardware and software project started to lever the argentinean industrial environment. The CIAA-ACC is a 12 layer PCB design for High Performance Computing. It has a Xilinx Zynq-7000 SoC with an ARM 2x Cortex A9 CPU and a Kintex-7 FPGA. The form factor is the expandable PCIe-104. Peripherals: 1GB DDR3 memory, Quad SPI Flash, Gbit Ethernet, Micro SDHC, USB 2.0, dual role HDMI, PCIe 1x.

View Project

Submit a new project

Want to showcase your project that you made with KiCad? Read how to add it
