Pi Hat Projects

ANAVI Flex HAT

Leon Anavi

ANAVI Flex is an open source Raspberry Pi HAT for IoT prototyping and home automation applications. It has infrared receiver and transmitter, relay, buzzer, button, RGB LED and UART pins for debugging. The board also supports 1602 LCD display module and up to 5 I2C sensors.

View Project

ANAVI Infrared pHAT

Leon Anavi

ANAVI Infrared pHAT is an add-on board that converts Raspberry Pi in a powerful remote control. It features two IR transmitters, IR receiver, three slots for I2C sensor modules, UART pins for debugging and EEPROM with board manufacturer information.

View Project

ANAVI Light pHAT

Leon Anavi

ANAVI Light pHAT is a Raspberry Pi add-on board for controlling 12V RGB LED strip. Furthermore, it has three slots for I2C sensor modules, slot for PIR motion sensor, UART pins for debugging and EEPROM with board manufacturer information.

View Project

Boatcontrol

Antonia Stevens (ant)

Boatcontrol is an open hardware design for a marine grade SMART/IoT electrical distribution panel and electronics platform (boat) controller.

It’s an I/O breakout board capable of switching 32 onboard latching relays and optionally 32 momentary/latching relays using addon boards switching up to 60A AC/DC 0-400V per circuit.

The "smart" part is provided by either a Raspberry Pi HAT or a Nvidia Jetson (Nano/Xavier NX) either of which can be mounted on the board.

View Project
